The main features of our new type:
1. The machine is controlled by mechanical system, it doesn’t need air compressor. It saves at least 6 KW power for our customer when the machine is running.
2. The hot wind blow from the heating tube, it makes the PE coated papers stick together more tightly.
3. Besides the mechanical system, the machine on one line producing very fluently: paper feeding, heating, forming, pulling out and collecting heating. The machine speed can be doubled as a result.
Besides, with the international trend of plastic restriction, we also provide more and more environmentally friendly products. In order to protect the environment, to contribute their own small force.
Specifications
| Type | AB-CHJ-D60 | AB-CHJ-D120 |
| Production capacity | 30-45pcs/min | 30-40 pcs/min |
| Suitable Material | 200–400g/㎡ single or double PE coated paper | 200–400g/㎡ single or double PE coated paper |
| Total Power | 4KW | 5KW |
| Total Weight | 1250KG | 1750KG |
| Overall Dimension | 2200 x1100 x 1500 mm | 2800 x1100 x 1900 mm |
| power source | 380V 50HZ | 380V 50HZ |
